HY-8030H
HY-8030H
Wire Cutting And Stripping Machine
Model | HY-8030H |
Display | 7 inch touch screen |
Function | Wire cutting and stripping (Sheated cable: outsider jacket and component wire ) |
Cable Type | Wire、PVC、Sheated Cable、Multi-core Cable，ETC |
Cable Size | 2-30 sqmm（include max.7 core sheated cable) |
Cutting Length | 1mm-99999.99mm |
Cutting Tolerance | ≤0.002*L |
Stripping Length | End 1: Sheated cable (full-stripping)10-120mm , Component wire 1-120mm |
End 2: Sheated cable (full-stripping)10-120mm , Component wire 1-80 mm | |
Max.Guide Size | Φ 16 |
Blades Material | High speed steel |
Production Capacity | 2300 pcs/h ; Sheated cable : 800pcs/h Depends on cable type ,length and size . |
Driver | 16 roller driver (Silent hybrid stepping motor and servo blades holder) |
Feeding mode | Belts feeding |
