HY-8010 Coaxial Wire Stripping Machine
Coaxial Cable Stripping Machine HY-8010
It is mainly used for processing the coaxial cable with big outer diameter and special single wire, it adopts the most advanced double-knife rotating tool-holder which improves the processing capacity, it can strip 9 layers at most and no need to replace the blade, the various size and outer wire can be processed correspondingly.
Technical parameters
Maximum processing wire diameter: 10mm Storage capacity: 100 kinds of cable processing data
Cutting depth unit: 0.01mm
Opening mode: manual/pedal (choose freely)
Maximum stripping length:80mm
Electric source: 220V/50Hz
Minimum stripping length: 1mm
Power: 380W
Maximum stripping layer: 9 layers
Weight: 26KG
Drive mode: motor/ball screw drive
Size: 620x230x360mm
Display mode: touch screen
Clamp device: automatic core adjustment, motor drive, clamping force program control
Productivity: 300-500pcs/h (depends on the wire type and length)
Work condition: 0-50 degree, moderate dryness, no vibration working table
