HY-1E Pneumatic Stripping Machine
Technical Specifications
Wire Size Range: 0.03-4.0mm2
Precision of Diameter Setting: 0.01mm (0.001")
Max. Outer Cable Diameter (Partial strip/full strip) Strip: 4.2mm
Length (Partial strip/full strip): 1-20/20mm (0.04-0.78"/0.78")
Graduated Full Strip Increments: 0.5mm
Graduated Partial Strip Increments: 6.0mm
Cycle Time (max. Stripping length): ca. 0.5 s
Stripping Blade: V-blades
Supply Power：110V/220V
Dimensions (LXWXH): 380X85X188mm
Weight (Net): 4.5kg
