HY-100BCO Corrugated tube cutting machine
Corrugated Tube Cutting Machine ZDQG-100B
It has a strong belt-type traction mechanism and utility knife cutting mechanism, with characteristics of fast speed, smooth incision, easy adjustment, small length error and low cost. This all-in-one machine combines with series of procedures of the first generation tube placing device, pre-sending device and tube cutting device, the same PLC controls all the motors which make it work more smoothly and more conveniently to adjust it.
Technical parameters
Type: ZDQG-100B
Size: L1500×W800×H1000MM
Weight: 400KG
Power: AC220V/60Hz
Packing size of corrugated tube: 800x400MM
Cutting length: 1-99999mm
Cutting position: non-wave crest
Transmission speed: 2m/s
